Burris Six Xe® — Riflescopes

Magnification families: 1–6×24 · 3–18×56 (RFP & FFP) · 5–30×56

Tech Highlights
• All models use a 30 mm main tube and illuminated reticles (CR2032) · 11 brightness levels with OFF between clicks · 2-hour auto-shutoff
• Side parallax on 3–18× and 5–30× models · Push-pull locking turrets on 3–18× & 5–30× · Zero-Click-Stop elevation (3–18× & 5–30×)

1) Itemized Components (Product Map)

Item #	Component	Function
1	Eyepiece / Diopter Ring	Focus reticle sharp to your eye (quick-glance method).
2	Power (Zoom) Ring	Set magnification; true 1× feel on 1–6×.
3	Elevation Turret	Zero & dial holds; Zero-Click-Stop on 3–18× & 5–30×.
4	Windage Turret	Point-of-impact left/right; push-pull lock on 3–18× & 5–30×.
5	Side Parallax / Focus	Parallax removal & image focus (3–18× & 5–30×).
6	Illumination Dial & Battery Cap	11 levels with OFF between; CR2032 “+” up.
7	Objective Lens	Primary light-gathering element (24 mm or 56 mm).

2) Models & Item Numbers

Model / Reticle	Focal Plane	Item #
1–6×24 · 3P #4	Rear (SFP)	200626
3–18×56 · Ballistic Plex E3	Rear (SFP)	200627
3–18×56 · 3P #4	Rear (SFP)	200623
3–18×56 · SCR 2 MIL	Front (FFP)	200624
3–18×56 · SCR MIL (18×)	Rear (SFP)	200628
5–30×56 · SCR MIL (30×)	Rear (SFP)	200625

3) Core Specifications (by family)

Spec	1–6×24	3–18×56 (SFP)	3–18×56 (FFP)	5–30×56
Tube Diameter	30 mm	30 mm	30 mm	30 mm
Objective Diameter	24 mm	56 mm	56 mm	56 mm
Focal Plane	Rear (SFP)	Rear (SFP)	Front (FFP)	Rear (SFP)
Field of View @100 m	31.4–5.9 m	11.7–2.0 m	11.6–2.0 m	7.1–1.2 m
Eye Relief	91 mm	91 mm	90 mm	92 mm
Exit Pupil (low→high)	7.5–3.6 mm	7.2–3.1 mm	7.6–3.1 mm	7.5–1.9 mm
Click Value	1 cm @ 100 m (0.1 MIL)	1 cm @ 100 m	1 cm @ 100 m	1 cm @ 100 m
Total Elevation	40.7 MIL	24.7 MIL	24.7 MIL	16 MIL
Total Windage	40.7 MIL	24.7 MIL	14.5 MIL	16 MIL
Length	27.5 cm (10.83″)	33.4 cm (13.15″)	33.5 cm (13.19″)	39.8 cm (15.67″)
Weight	500 g	770 g	780 g	760 g

4) Quick Start (Focus, Parallax, Zero)

Eyepiece focus: Look at sky/plain wall and take quick glances while turning the diopter until the reticle snaps crisp/black.
Parallax (3–18× & 5–30×): Rotate side focus until the target is sharp and the reticle no longer “floats.”
Turret locks: On 3–18× and 5–30×, pull caps up to unlock, push down to lock.
Zero-Click-Stop (elevation): Remove cap → loosen ring set-screws → turn ring fully clockwise → snug screws → reinstall cap with “0” aligned.

5) Reticles by Family

Family	Reticles
1–6×24	3P #4 (illuminated)
3–18×56 (SFP)	3P #4 · Ballistic Plex E3 · SCR MIL (18×)
3–18×56 (FFP)	SCR-2 MIL
5–30×56	SCR MIL (30×)

6) Mounting, Power & Care

Rings: All Six Xe models require 30 mm rings. Use quality bases/rings and level the scope carefully.
Illumination: 11 positions with OFF detents between settings; CR2032 battery installs “+” up inside the dial cap.
Environmental: Waterproof/fogproof. Blow/brush grit before lens tissue; rinse heavy mud with water/lens fluid.
Service: Do not disassemble; contact Burris for support. Covered by the Burris Signature Warranty™.

User Guide (PDF): Six Xe® Riflescopes — User Manual (INST-9505)
