Signature HD Spotting Scope

Burris Signature HD® — Spotting Scope (Green)

Model: 20–60×85 (angled)  |  Finish: Black / Green

Tech Notes
• Built-in retractable sunshade reduces glare and helps in rain/snow.
• ARCA-Swiss compatible tripod foot (also accepts 1/4″-20 plate).
• M-LOK® slots near the eyepiece accept a universal red-dot plate (included) or a short Picatinny rail; great for mounting a FastFire® to speed target acquisition.
• Centrally located fine-focus ring for quick, precise focusing; twist-up eyecup for eyeglass use.
• Rotating collar with thumbscrew lets you set a comfortable viewing angle when standing, seated, or prone.

1) Itemized Components (Product Map)

Item #	Component	Function
1	Eyepiece w/ Twist-up Eyecup	Comfort/eye relief; twist down for glasses.
2	Magnification Adjustment Ring	Zoom 20× → 60× (field of view narrows as power increases).
3	Fine-Focus Ring (Center)	Crisp focus; use after setting magnification.
4	Retractable Sunshade	Slides forward to reduce glare/stray light; adds weather protection.
5	Objective Lens (85 mm)	Primary light-gathering element (HD, apochromatic system).
6	ARCA-Swiss / 1/4″-20 Tripod Foot	Direct clamp to ARCA heads; or mount with standard 1/4″-20 plate.
7	M-LOK® Accessory Slots	Accepts included universal red-dot plate or short rail.
8	Rotating Collar & Thumbscrew	Loosen to rotate the body; tighten to lock viewing angle.

2) Item Numbers (SKUs)

Product	Item #	Color
Signature HD Spotter 20–60×85 (angled)	300103	Black / Green

3) Setup & Use

Step	What to do
Attach eyepiece	Align eyepiece mark with the red dot on bayonet; insert and turn clockwise until it clicks. Press release tab to remove.
Mount to tripod	Clamp directly to ARCA head or use a 1/4″-20 quick-release plate. Apply light forward pressure in the rail slot before tightening.
Set magnification	Start at lower power for widest FOV; turn the zoom ring left (counter-clockwise) to increase power, right to decrease.
Fine focus	After setting magnification, slowly turn the center focus ring until the subject is crisp. Re-touch focus as distance changes.
Set viewing angle	Loosen the collar thumbscrew, rotate the body to a comfortable angle (standing/seated/prone), then retighten.
Use sunshade	Slide the objective hood forward to reduce glare and protect from weather.

4) Accessories

Accessory	Details	Included?
Universal Red-Dot Mounting Plate (M-LOK®)	Multiple footprints supported: FastFire/Docter, RMR, RMSc, RMS/SMS, DeltaPoint (thread patterns #6-48, #6-32, M4).	Yes
30× Wide-Angle Eyepiece (SCR MIL or SCR MOA)	Fixed 30×; etched reticle for precision/spotting impacts.	Sold separately

5) Core Specifications

Spec	Value
Magnification	20× (±5%) to 60× (±5%)
Objective Diameter	85 mm
Field of View @ 1000 yd	110 ft (low) · 55 ft (high) ±3%
Eye Relief	19.7 mm (low) · 18 mm (high) ±5%
Focus Mechanism	Fine-focus central ring
Length	16.25″ (zero diopter)
Weight	70.4 oz
Waterproof Rating	IPX7
Operating / Storage Temp	5°F to 140°F / −5°F to 150°F

6) Care & Maintenance

• Fully waterproof & fogproof. Avoid disassembly; all assemblies are factory-lubricated.
• Before wiping, remove grit with a Lens Pen® or soft brush while gently blowing on the lens. For dried mud, rinse with clean water or lens fluid first.
• Keep lens caps on when not in use; reinstall the rubber M-LOK® covers if you remove accessories.

---

User Guide (PDF): Signature HD® Spotting Scope — User Guide (Green)
