Scout Scopes

Burris Scout™ — Riflescopes

Models: 2.75×20 (fixed) · 2–7×32 (variable)  |  Main tube: 1″  |  Reticles: Ballistic Plex™ · Heavy Plex

Tech Notes
• Designed for forward mounting (ahead of the ejection port) for both-eyes-open use and fast target acquisition.
• Very long eye relief (Scout concept), low-profile finger-adjust turrets, and Hi-Lume® multicoating for low-light performance.
• Click values differ by model: ½ MOA on 2.75×; ¼ MOA on 2–7×.

1) Itemized Components (Product Map)

Item #	Component	Function
1	Eyepiece / Diopter Ring	Focus reticle crisp/black (quick-glance method).
2	Magnification Ring (2–7× model)	Set zoom (use highest power for Ballistic Plex holds).
3	Elevation Turret (capped)	POI up/down; ½ MOA (2.75×) or ¼ MOA (2–7×).
4	Windage Turret (capped)	POI left/right; firm, audible clicks.
5	1″ Main Tube	Nitrogen-filled, waterproof, shock-resistant body.
6	Objective Bell / Lens	Primary light-gathering element (Hi-Lume® coated).
7	Turret Caps	Protects from dirt/moisture; prevents accidental moves.

2) Models & Item Numbers (SKUs)

Model	Item #	Reticle	Notes
Scout 2.75×20 (fixed)	200269	Heavy Plex	Long eye relief; ½-MOA clicks; classic plex.
Scout 2–7×32 (variable)	200261	Ballistic Plex™	¼-MOA clicks; long eye relief; capped hunter knobs.

3) Quick Start — Mount • Focus • Zero

Step	Guidance
Mount forward	Install ahead of the ejection port for both-eyes-open shooting and clear port access. Use quality rings/bases.
Eyepiece focus	Glance at sky/plain wall and turn diopter until the reticle “snaps” black. Don’t stare while turning.
Set clicks	2.75×: ½-MOA per click · 2–7×: ¼-MOA per click (use a coin if needed).
Zero	Confirm at 100 yd (or 200 yd per your cartridge). For Ballistic Plex: set to highest magnification when using the holdover marks.

4) Using Ballistic Plex™ (2–7× model)

• Sight-in: exactly 100 or 200 yd based on your load; set scope to max power for holds.
• Map your drops: Shoot and record drop at 100-yd increments to tag each stadia to your cartridge.
• Use: Range/estimate distance → choose the corresponding ballistic line; slight hold-over/under for in-between yardages.

5) Core Specifications (by model)

Spec	2.75×20 ( Item 200269)	2–7×32 ( Item 200261)
Focal Plane	Rear (SFP)	Rear (SFP)
Eye Relief	8.5–14″	9.2–12″
Field of View @100 yd	15 ft	23–8 ft
Click Value	½ MOA	¼ MOA
Elevation / Windage Travel	140 / 140 MOA	66 / 66 MOA
Parallax / Focus	Fixed @ 100 yd	Fixed @ 100 yd
Length	—	9.7″
Weight	—	13 oz

6) Care & Service

• Waterproof & fogproof. Remove grit before final cleaning; for heavy dirt/mud, rinse with clean water or lens fluid, then finish with a soft brush/Lens Pen.
• Do not disassemble; assemblies are factory-lubed. Contact Burris Customer Service for issues. Covered by the Burris Signature Warranty™.

---

User Guide (PDF): Scout™ Riflescopes — User Guide
