Burris Eliminator® 5 — LaserScope 5–20x50mm

Item: 200155 (X96 Reticle)

---

1) Physical Components

Item #	Component	What it does
1	On/Range Button (Left)	Turns unit on / ranges target; shows range, wind hold indicator & holdover dot.
2	On/Range Button (Right)	Duplicate control for ambidextrous use.
3	Forward Button	Enter/advance in setup; confirm selections.
4	Up Button	Increase values; raise reticle brightness.
5	Down Button	Decrease values; lower reticle brightness.
6	Battery Cover	Houses batteries (see Power section).
7	Parallax Adjustment	Focus/parallax from ~30 yds to infinity.
8	Elevation Knob	Zeroing adjustments (1/8 MOA clicks).
9	Windage Knob	Zeroing adjustments (1/8 MOA clicks).
10	Objective Lens (50 mm)	Primary light-gathering lens.
11	Eyepiece & Diopter	Focuses display to your eye.
12	Integrated Mount Base	Mounts directly to Weaver/Picatinny—no rings required.

2) Core Specifications

Category	Detail
Magnification / Objective	5–20× / 50 mm (ocular 42 mm)
Reticle	X96 with holdover dot & 10 mph wind value display
Rangefinder	Laser ranging to ~2,000 yd (target-dependent)
Click Value / Travel	1/8 MOA; Elevation 50 MOA; Windage 50 MOA
Parallax / Focus	~30 yds to infinity (side focus)
Field of View (100 yds)	22–5.8 ft
Eye Relief / Exit Pupil	3.5–4 in / 10–2.5 mm
Length / Weight	15.5 in / 28.8 oz
Power	2 × AAA batteries
Mounting	Direct to Weaver/Picatinny base (no rings)

3) Quick Setup (Zeroed at 50 / 100 / 200 yds)

1. Enter Setup: Turn the scope on, Press & hold Forward, then press & hold either On/Range button for ~6 seconds; release.
2. Units: Choose Y (yards) or M (meters) with Up/Down; press Forward to confirm.
3. Zero Distance: Select “0” (50 yd), “1” (100 yd), or “2” (200 yd); confirm with Forward.
4. Drop Number: Set the three-digit Drop Number; press Forward to advance.
5. BC Value: Set the two-digit BC; press Back to save & return to shooting mode.

Tip: Verify your Drop # / BC at long range. If the group prints low at max power, increase the Drop # by the inches low (and vice versa).

4) Operation & Displays

• Press either On/Range to range. The scope displays range, a 10 mph wind value (dots of hold), and illuminates the holdover dot for the correct aim point.
• After ~10 seconds, unit/range/battery icons turn off, but the holdover dot & wind value remain ~90 seconds (until re-range or magnification change).
• Use Up/Down to adjust reticle brightness during normal operation.
• Remote: Wireless Bluetooth remote provide
